Wilson’s Carpentry and joinery / by John Wilson (1891)
Wilson, John · Manchester [England] : Percy Bros. · leaf 100
When the glue is hard, wedgethe pulley stiles, into the sill; remove the cylinder and cut the head out tothe development. To work this, notch a straight edge out at one end to thethickness of the casings; this notch is kept on the sill working off tb« headuntil the straightedge touches the piece M,… … lDo CIRCLE UPON CIRCLE.-Conttnuei. Fig. 1. A B C D is the plan, and E F G the elevation ol a eiroular-headed frame, oiroular in plan, the head to be in tliree pieces. The jointsmay be arranged at pleasure exoept that they muBt be at equal distances fromthe springing line E G, whioh is also used as…
Carpentry · Joinery
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
