Wiring diagrams of electrical apparatus and installations (1913)
McGraw-Hill · New York, McGraw-Hill Book Company · leaf 115
Fig. 167.—Connections of self-contained auto-starter for two-phase induction motor withsquirrel-cage secondary. Rating: 300 amp. per phase up to 550 volts. … Fig. 168.—Polyphase induction motor. Starting panel. ALTERNATING CURRENT MOTORS AND SPEED CONTROL 105 Trip Coll-t
Electric wiring
