Wiring diagrams of electrical apparatus and installations (1913)
McGraw-Hill · New York, McGraw-Hill Book Company · leaf 125
Fusei. SforHng-Box. Fig. 186.—Arrangement of apparatus for starting split-phase motor shown in Fig. 185. 114 WIRING.DIAGRAMS OF ELECTRICAL APPARATUS … Line Fig. 187.—Connections for starting single-phase induction motor with three-pha.se wind-ing. The phases are independent and arranged so as to be connected in star when starting, andin delta when running.
Electric wiring
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
