Wiring diagrams of electrical apparatus and installations (1913)

McGraw-Hill · New York, McGraw-Hill Book Company · leaf 20

An illustration from Wiring diagrams of electrical apparatus and installations, 1913, leaf 20 — P/?eostaC y Syv/CcA Fig. 15.—Low voltage direct-current generator panel with circuit breaker. Rating: 5 to 120kw., 125 volts, or 10 to 240 kw., 250 volts. Voltmeter to be mounted on swing bracket. DIRECT CURRENT GENERATORS -GrourxJOetecCor Lainps- … FlG . 16.-Small plant direct-current switchboard for generator and feeders.

Electric wiring
