lic veins, is a fair insulator,but the frequent occurrence of such veins, and the tendency of slateto absorb moisture from the air, render it unreliable, especiallyfor switchboards on which high-voltage apparatus is to be installed. A-FC/SE HOLDER B-/IMM£TS/i C - VOL TMETE/f D - VOL TME TEfi… … Fig. 365. Front Elevation and Connections for Board Shown in Fig. 364 Marble is the standard material for switchboard panels, and it onlyis used for high-voltage panels. Typical Single=Phase Switchboard. Fig. 364 shows a frontview of a standard switchboard for one single-phase generator andtwo…
