The wonders of modern mechanism. A résumé of recent progress in mechanical, physical, and engineering science (1896)

Cochrane, Charles Henry, 1856- · Philadelphia J.B. Lippincott · leaf 164

An illustration from The wonders of modern mechanism. A résumé of recent progress in mechanical, physical, and engineering science, 1896, leaf 164 — BRAZING A BICYCLE FRA3IE. illustrated. Brazing is not equal in strength to welding,therefore the joints are lapped to allow of the brazing of a Fi(i. 82. … THE WAVERLEY BRAZED JOINT. larger surface and to get greater strength. Borax and zincare used to assist the brazing, and when the work is done 156 WONDERS OF MODERN MECHANISM. and cooled it is washed in acidulated water to remove theborax. The frame then goes to a filer, who smooths upthe joints,…

Inventions · Mechanical engineering · Machinery

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
