Wood pattern-making; the fundamental principles and elementary practice of the art (1906)

Purfield, Horace Traiton · Ypsilanti, Mich., The Scharf tag, label & box co. · leaf 113

An illustration from Wood pattern-making; the fundamental principles and elementary practice of the art, 1906, leaf 113
Oliver Trimmers … PUIvIvEY PATTERNS 99 allowed to dry. After the glue is dry, the brads may bepulled out and the chuck put in the lathe and the ringfaced off, making it true in both directions. The nextlayer may now be put on in the same way. The ends ofthe cants should be placed about in the center of thosein the…

Patternmaking
