An illustration from Wood pattern-making; the fundamental principles and elementary practice of the art, 1906, leaf 149 — or this class of work is called loam. One example of this class of patterns is shown byFig. 79. It is a skeleton pattern of a pipe bend, fromwhich only one or two castings are wanted. The drawingsgive a good idea of the general make-up of the pattern. 134 WOOD PATTERN MAKING The core and method of… … If! m WaiVnit
