Woodwork for the grades, for use in manual training classes; fully illustrated with three hundred half-tone engravings from actual shop practice, and many working drawings of educational shop problems (1913)
Selden, Frank Henry · Chicago, Orr & Lockett Hardware Co · leaf 122
Fig. 159—Planing Curve WOODWORK FOR THE GRADES 119 LESSON 33 MANTEL SHELF If you have made successfully all the pieces up to Lesson30, you should be able to make this shelf. Work each pieceto the sizes given in the drawing, (Fig. 162) … Fig. 160—Mantel Shelf i 7 jk r.-Jr \ Fig. 161 — Testing A ngle of Brackets 120 WOODWORK FOR THE GRADES By making the shelf supports or brackets in one piece asshown in Fig. 163 and then cutting them apart, you will be able to make them nicer and inless time than by working eachpiece separately. The…
Woodwork
