d in eachleg it may be located in the samemanner as the screw. (Fig. 171)The other method of securingthe legs is shown in Fig. 171.Screw fastenings of this sort maybe used in many places. Fig. Fig. 16 7—Marking for Dowels 172 is a drawing showing howthe leg and screw would appearif cut through…
