Woodwork for the grades, for use in manual training classes; fully illustrated with three hundred half-tone engravings from actual shop practice, and many working drawings of educational shop problems (1913)
Selden, Frank Henry · Chicago, Orr & Lockett Hardware Co · leaf 128
Fig. 168 Setting Gauge WOODWORK FOR THE GRADES 125 … Fig. 169—Lining for Dowel After the end of the leg has been squared the center is located and a hole is bored large enough to receive the head of the screw and just deep enough to allow the head to rest on the bottom of the hole. It is essential that the hole be of the required depth. A piece of…
Woodwork
