Fig. 222— Testing with Framing Square 160 WOODWORK FOR THE GRADES square as in Figs. 219, 220 and 221. The framing square maybe applied as in Fig. 222. You may be able to press the parts together without usingany clamps but do nottry to drive them to-gether. By referringto Fig. 229 you willlearn… … Fig. 223- Turning Rung Fig. 223. If one endenter too easily it maybe held back by placing a hand-screw as shown in Fig. 224. After each pair of legs has been put together and the glueallowed to dry, glue the pairs together in a similar manner,testing them thoroughly.They may be tested forsquareness…
