Woodwork for the grades, for use in manual training classes; fully illustrated with three hundred half-tone engravings from actual shop practice, and many working drawings of educational shop problems (1913)
Selden, Frank Henry · Chicago, Orr & Lockett Hardware Co · leaf 192
t the piece to the finished length.Draw pencil lines for the end ofthe taper near the center. Drawgauge lines for the thickness attheends. (SeeFig. 249.) Planeto these lines. Hold the pieceagainst the stop in planing. Usea block between the stop and thepiece to avoid bruising the end.Draw a line on… … Fig. 264—Blotter Pad 190 WOODWORK FOR THE GRADES against the stop, you can place it in the vise as shown in Fig.265. Part of the time the plane may be held at an angle ofabout 45 degrees and moved across from edge to edge, andpart of the time the plane may be held parallel with the edgesand moved…
