you are planing up to thelight and place the bladeof the try-square acrossthe face as shown in Fig.25. If the blade of thetry-square touches thesurface at all points thesurface is correct astested from edge to edge. If the try-square does nottouch all the surface the piece isincorrect and instead… … Fig. 28—End View of Plane 30 WOODWORK FOR THE GRADES near the center of the cutting edge, therefore the center of thecutting edge should be moved over the high places as shownin Fig. 28. In this case the plane is moved so it will cut a shavingnear one edge. Continue planing in this manner until the…
