e the piece and determinewhich edge is to be the face-edge before making the mark onthe first surface. If the piece is to be cut up into two or morepieces, face-marks should be placed on the surface so thatafter the parts are separated there will be a face-mark on eachpiece. LESSON 8 KEEPING THE… … If you have a board which has not been machine planed or surfaced, brush all grit and dirt off the surface before begin-ning to plane it. By being careful to plane systematically, you will true the surface with much less planing, and thus not only do better work, but also will use the plane so much…
