sthan the thicknessof the piece toallow for planingthe scale off anddraw lines alongeach edge. Exam-ine the scales and plan to plane off the poorer one. After tne lines have been drawn, plane off the scale andtest the piece as you tested the fourth side, Lesson 12. Bevery careful to plane exactly… … Fig. 64 — Selling Try-square at Corner WOODWORK FOR THE GRADES 59 Extend all the lines which mark the half inches on the scaleentirely across the surface. Extend these lines down on eachedge to the lineswhich are 3/ic inchfrom the otherside. Be very care-ful to havethe linesmeet exactly at…
