Woodwork for secondary schools; a text-book for high schools and colleges, prevocational and elementary industrial schools (1916)
Griffith, Ira Samuel, 1874-1924 · Peoria, Ill., Manual Arts Press · leaf 186
DflAWEHCOflNER- Fig. 277. JOINERY. 181 … Fig. 278. Setting T-BevelFROM Drawing. 165. Hopper Joint.-^The hopper joint is laid out andworked as follows: (1) Work the members to theproper width. (2) Plane the upper and lower edgesto the proper bevel. The set-ting of the T-bevel may be ob-tained by setting it upon thedrawing, Fig. 278. (3)…
Woodwork (Manual training)
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
