Woodwork for secondary schools; a text-book for high schools and colleges, prevocational and elementary industrial schools (1916)
Griffith, Ira Samuel, 1874-1924 · Peoria, Ill., Manual Arts Press · leaf 203
SECONDARY SCHOOLS. shallower depth at the middle than he realizes he hasneed of. The cutting must take place from the shallowertoward the deeper part of the taper cut always, of course.180. Laying Off Consecutive Measurements.—Wherea number of like spindles are to be turned, consecutivemeasurements… … FiG. 308. Cutting V-Grooves. manent templet, and one from which the measurementsare more quickly transfered, is obtained by driving smallbrads into the edge of the wood at the points required,snipping off the heads and filing the projecting ends tosharp marking points. This templet is pressed…
Woodwork (Manual training)
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
