Shop practice for home mechanics, use of tools, shop processes, construction of small machines. Contains a chapter also on theoretical mechanics and on miscellaneous information relative to shop work (1920)
Yates, Raymond F. (Raymond Francis), 1895- · New York, N. W. Henley Pub. Co. · leaf 290
worth the time and trouble whenone can be had for about $3.00. The handle which actuates the drill press is now made. Construction of Small Power Driven Drill Press 289 This is such a simple part of the machine that it seemsneedless to describe the operations involved in making it.The socket is now… … Fig. 298B—Drilling the dimple in the end of the spindle volves a few^ simple lathe operations which can be deter-mined by a glance at the drawing. After the slot is cutwith a hack saw it should be filed nice and smooth sothat there will be no danger of friction between it andthe handle. Before the…
Machine-shop practice · Handicraft
