Fig. 71. Planing Dado Joint. 46 WOODWORK FOR SECONDARY SCHOOLS. 53. Plow and Matching Plane.—The plow is used tocut grooves along the grain. By an exchange of cuttersvariotis sized grooves may be worked. An adjustable fh^^K … AR.M6 Fig. 72. Plow and Matching Plane. fence determines the distance of the groove from the edgeof the board while a depth gage limits the depth. Theplane shown in Fig. 72 is a combination plane which may be used as a plow, dado, filletster,and matching plane. The length is10|. Plow and dado bits…
