case respectively is costly; hence it isnot the general practice in cheap work. 103 The Hinged Joint OUTSIDE HINGEING. Fig. 244 illustrates the portion of a door frame andcarcase end when the door is hung on the face of thecarcase. The correct method of letting in the hinge isshown in the enlarged… … Fig. 246.—Fall Front of Writing Bureau. occasionally a bead mould is worked on the edge of thedoor so as to give a finish and partly hide the joint. Thebead would, of course, be the same size as the diameterof the knuckle of the hinge; and the knuckle, therefore,will form a continuation of the bead…
