Woodwork and mechanical drawing (1914)

Fox, William Paul. [from old catalog] · Chicago, Ill., Fox brothers · leaf 11

An illustration from Woodwork and mechanical drawing, 1914, leaf 11
table handles.The frame is wood, with an iron or rope tie-bar. (5) The Coping Saw, for circular and irregular shaped cut-ting of thin boards. This saw has a narrow blade about 32 wide,with small teeth, and a metal frame. It is very important that a saw should be set correctly, thatis, it must cut…
