6 wide. Plane to 5y2x5y2. Mark for tV chamfer aroundthe top surface of the board witha marking gauge, Figs. 35 and 36. Plane chamfer, planing the endsfirst. Use a diagonal stroke so asnot to break the edges, Fig. 37, orplane the chamfer, cutting two-thirds across the width of the boardand then… … , FIG. 37 0 ■A ■ sI Iz 2 li~ ^ £ -Calendar Baca S, LESSON NO. 7 CALENDAR BACK Plane board 10x5x3/8. Markl1/^ from top and two sides, andS1^ from the bottom, using themarking gauge, Fig. 38. Bore tV hole at any point inenclosed figure with hand gimlet toput the coping saw through. Saw out opening…
