H c I fi Ik I 3k w> FIG. B3 … On piece No. 3, true all edges. Take a fine cut off all surfacesof the three boards with a smooth-ing plane. This will make themsmooth and clean. Then sandpaper. After sandpapering, lay out thefollowing light lines with a sharppencil on piece No. 1; a center linefrom top to bottom on both sidesof…
