Working drawings and how to make and use them (1881)

Haupt, Lewis M[uhlenberg], 1844- [from old catalog] · Philadelphia, J. N. Stoddard & co. · leaf 78

An illustration from Working drawings and how to make and use them, 1881, leaf 78 — POINTS … Scale in inones.Full Size. ■i i i i -i—r FIGS. 3-4. REVOLUTION of POINTS and PLANES
