Wright aircraft engines; complete instructions for their installation, operation and maintenance; (1921)
Wright Aeronautical Corporation, Cautley, John R., ed · Paterson, N.J., Wright aeronautical corporation · leaf 18
These views show the Model H-2 Wright Enginewith complete standard equipment, as sent out fromthe Wright plant. H-3 identical externally except formodified water connections. V^: -SJ WRIGHT AERONAUTICAL ENGINES … Explanatory diagram of valve tappet adjustment which mesh with those on the underside of the tappet.The hole in the center of the washer is not circular butis made to fit slots cut on the top end of the valve stem,and around the periphery of this washer are a number ofsmall holes. The valve springs…
