Yarn and cloth making; an economic study; a college and normal schools text preliminary to fabric study, and a reference for teachers of industrial history and art in secondary and elementary schools (1918)
Kissell, Mary Lois · New York, The Macmillian company · leaf 118
ts and run bypower. Attenuating device: series of pairs of drawing rollers. 72 YARN AND CLOTH MAKING Twisting device: the automaticflyer, cap or ring spindle. Winding device: the automaticwinding spindle. Continuous spinning. Outline Examples: Flyer spinning frame ;Cap spinning frame; Ring… … Fig. 28. — Ring Spindle Bobbin (black) firmly at-tached to spindle (white)which twists. Lifter ringplate (gray) with travel-ing hook; drag of yarnthrough hook winds on. Fig. 29.- F. Cone-shaped cap attached to stationary spin-dle; the drag of yarn on cap-edge winds on. /. Tubular bobbin revolving…
Textile industry · Spinning · Weaving
Internet Archive Book Images · The Library of Congress · No known copyright restrictions (public domain). Free to use for anything.
