Barker, A. F. (Aldred Farrer), b. 1868, Gardner, Walter Myers, 1862- [from old catalog], Snow, R. [from old catalog], Cook, William Hall. [from old catalog], Bradbury, Fred. [from old catalog] · New York, D. Van Nostrand company · leaf 129
nding thespindle is the ring—or, conversely, the spindle passes exactlythrough the centre of the ring, and upon this ring, suitablycontrolled by the ring-flange, is a traveller. The sliver,instead of passing directly to the apex of the spindle, firstpasses through the traveller and then on to the… … Fig. 15.—Eing Spring Frame.—A, back rollers; B, carriers;G, front rollers; D, eyelet board; E, spindle ; F, spindlesupport; G, spindle wbarl; H, tin drum round which spindleband passes; /, ring; J, traveller. THE PRINCIPLES OF SPINNING 109 bobbin by the slow movement up and down of the…
Textile industry and fabrics
