A manual of elementary geometrical drawing, involving three dimensions. Designed for use in high schools, academies, engineering schools, etc. : and for the self-instruction of inventors,artizans, etc. ... In five divisions .. (1867)
Warren, S. Edward (Samuel Edward), 1831-1909 · New York : J. Wiley and son · leaf 108
rge or complicatedstructures, as buildings or machines, when shown in isometricalprojection, causes this method to be confined, in its application, tosmall objects, details, &c. 205. It is often convenient to know in advance the extremeheight of the isometrical drawing of a given object, in order… … The MajoriKnaiip Eni.HrviLith.Ca4« DmndwayHY. CHAPTER n. PROBLEMS IlSrVOLVING ONLY ISOMETRIC LINES. 206. Prob. 1. To make the isometrical drawing of a cube, froma given plan and elevation. \st Method. The plan and elevation, PL IX,, Fig. 98, repre-sents a cube, whose edge is one inch in length,…
Geometrical drawing · Mechanical drawing
Internet Archive Book Images · The Library of Congress · No known copyright restrictions (public domain). Free to use for anything.
