are the radii of small semicircles of the hemisphere, to which projec-tions of rays of light may be drawn tangent, and m and g\ arethe true positions of their centres—ym being equal to nm, andyg equal to ng. Drawing arcs of such semicircles, and drawingrays, fd and rS, tangent to them, we determine…
