Creighton, William Henry Paul, 1859- · New York, J. Wiley & sons · leaf 376
Fig. 185.—Stephenson Link. (From Peabodys Valve-gears.) REVOLUTION CONTROL. 355 … FlG. 186.—Stephenson Link. (From Peabodys Valve-gears.) 356 THE STEAM-ENGINE AND OTHER HEAT-MOTORS. the valve. In other words, the axis of stresses in the valve-stemand in the eccentric-rods coincides with the axes of those rods.The figure also illustrates another form of link called the…
Steam-engines · Heat-engines
Internet Archive Book Images · The Library of Congress · No known copyright restrictions (public domain). Free to use for anything.
