provide a means by which steammay be employed expansively at pleasure. The link motion is representedin Fig. 10, where A, B, are two eccentrics oppositely placed on the driving- THE LOCOMOTIVE. 17 shaft, and their rods joined to the ends of the curved bar or hnk, CD. AsHt extends nearly the whole… … ggs^ Fig. 10.—StephensojHs Link Motion. of the link and the eccentric rods is counterpoised with a weight, K, at-tached to the lever, l K, which turns on the fixed centre, L. This leverforms one piece with another lever,- L M, with which it may be turned bypulling the handle of O p, connected with…
