ished to pass over thelink-block, B, when the link is raised to bring the eccentric, Ef,into full gear. The link is suspended on one side by the hanger?w?o from the bell-crank RSn keyed to the reverse-shaft S. Thereach-rod, attached to SR at R, is actuated from a reversing leverin the cab. The link… … Fig. 185.—Stephenson Link. (From Peabodys Valve-gears.) REVOLUTION CONTROL. 355
