Perspective and geometrical drawing adapted to the use of candidates for second and third-class teachers' certificates (1887)
McGuirl, Thomas H. (from old catalog) · Toronto, W. Briggs · leaf 105
= AD = AC = 4\ (Eig. 61.) Example 2.—Draw a cube, edges 4, right face at an angleof 60° and left face at an angle of 30° with P.P. H = 6,L.D. = 4^, scale Y = !• Cube to have an angle 4^ to left and2 within P.P. Draw H.L., B.L. and 00 as before; find also C.Y., R Y.P.,L Y.P., R MP, L MP and MP… … MISCELLANEOUS EXERCISES. 101 Exercise XY.—Figures in Angular Perspective,(In the following consider H = 6^ L.D. = i, scale ^ - V.) 1. A square whose sides are 4^, lies on ground; an angletouches P.P. 2 to right; angle 45°. 2. Draw same, 3^ to left arid 2 within P.P.; right side makesangle of 60°.…
Geometrical drawing · Perspective
Internet Archive Book Images · The Library of Congress · No known copyright restrictions (public domain). Free to use for anything.
