les a p v and a v t, e b: ef : : p v : v t. Therefore p v : v t :: e b : a e. And, by construction, angle tpy — z aeb. THE ELEMENTS OF PERSPECTIVE. Therefore the triangles t v p, a e b, are similar ; and t i> isparallel to a b. Now the construction in this jDrohlem is entirely general forany… … Fio. 77. f^g V p in p, p will be the vanishing-point of a b, and (by thesame proof as that given at j^age 21.) of all lines parallel to it. Next, to find the dividing-point of the inclined line, I remove some unnecessarv lines from the last fijnire and r^peat it here, Fig. 77., adding the…
