Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1914)
Griffin, Charles Lewis, 1867-, Adams, Charles Clyde, 1882- joint author · Chicago, American technical society · leaf 238
ation of some ofthe electrical features may be left to the designing draftsman. In general, the designing draftsman is supplied with completetables of the electrical features giving all details of the variouswindings, the length or size of the magnetic circuits, and the mate-rial to be used for… … 224 MACHINE DRAWING PRELIMINARY LAYOUT SKETCH Pencil Sketch. The designing draftsman may make firsta sketch or preliminary drawing showing the outline of the machine,with such dimensions as may be determined from the designers data. PLATE A. GENERAL OUTLINE DRAWING Plate A shows such a preliminary…
Machinery
