Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 145

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 145
340. THE SIROCCO FAN BLOWER. A … The particular featureof this fan is in thenarrow curvedblades set in theperiphery of thewheel and close to-gether, which pre-vents local eddiesand greatly in-creases the effi-ciency of the fan.Davidson patent. 341. Section showing shaft and bracing to the blade drum.

Mechanical movements
