Mechanical drawing for trade schools (1909)
Leeds, Charles Carley, 1870- [from old catalog] · New York, D. Van Nostrand company · leaf 114
s a chipping strip, or a narrow strip of metal thatmay be chipped and filed until the two edges of the castings match.These narrow strips of metal are more quickly and easily matchedthan wider surfaces would be. The chipping strip shown on the halves of the generator frameillustrates the value of… … ItemNo. Description and t^aterial Pat No. Req. 0 Hatf frame, C. 1. M. 7064 2 © tfE^s Bolt; W. 1. 2 ® 1x5Ivf.B.Tap Bolt, W.I. 12 @ ixSiStud Bolt with S.F:Nuts 1 © ix4-Si ■• - - - 1 ® ixTfxBWasfier, WJ. 2 /Drill and slot2gCbr,ideep /i Drill For pole details see Dwg.B-IO-4049For liners see Dwg.CI…Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
