Collins, A. Frederick (Archie Frederick), 1869- · Boston, Small, Maynard and company · leaf 41
however small or large as you havehad occasion to observe in the first chapter, andthere are, (i) the boiler which generates thesteam and (2) the engine which transforms theenergy of the steam into rotary mechanical mo-tion, which means in everyday English that theforce of it turns a wheel around.… … 7X-, CORK INLJ—FILLER HOLE SOLDERCOVER WIREFRAME TO HOLDBOILER. ■ALCOHOL Fig. 15. Side View of Turbine 26 Two Simple Steam Turbine Engines 27 Now solder the nozzle over the %-inch hole inthe can and dont be afraid of using too muchsolder. Cut out two strips of sheet brass, copper orheavy tin V2…
Steam-engines
Internet Archive Book Images · The Library of Congress · No known copyright restrictions (public domain). Free to use for anything.
