The internal combustion engine; being a text book on gas, oil and petrol engines, for the use of students and engineers (1909)
Wimperis, Harry Egerton, 1876- · New York, Van Nostrand · leaf 278
sliding shutter (see dotted lines) which is con-nected to the mechanism of the governor as already illustrated.The shape of the port is so designed as to give the area of OIL AND PETROL ENGINES 257 opening shown to be necessary by the curves experimentallyobtained (see Fig. 88). Another port—called… … Hoi Water Jacket Load Air Inlet J \, ) Lever for operating Speed Air Inlet Fig. 89.—Albion Carburettor. far as possible and free from any interference on the partof the driver. 116. A carburettor which has no additional air inlet andrelies upon keeping the correct mixture by manipulating thejet is…
Internal combustion engines
