Collins, A. Frederick (Archie Frederick), 1869- · Boston, Small, Maynard and company · leaf 252
the journal boxes and screw anut on the end of the shaft that carries the bevelgear. The Flywheel and Pulley.—The flywheel shouldbe a heavy one with at least a %-inch face and itshould be 5 inches in diameter. A spoked wheelof this size can be bought ready to use. It is a good scheme to fit a… … 237 238 The Boys Book of Engine-Building of the connecting rod and also in each bearingof the crankshaft and dont forget to oil up allthe other little parts often. How the Gas Engine Works.—The way asingle cylinder gas engine works can be easilyunderstood by looking at the diagrams shown inFig. 80.…
Steam-engines
Internet Archive Book Images · The Library of Congress · No known copyright restrictions (public domain). Free to use for anything.
