Perspective and geometrical drawing : adapted to the use of candidates for second and third-class teachers' certificates (1887)
McGuirl, Thos. H. (Thomas H.) · Toronto, Ont. : W. Briggs · leaf 66
t it in G; describe semi-circle, and complete oblong APQB; join GP, GQ, cuttingcurve in R, S ; draw^ RF, SH J_ to AB; join A C.V. Erectat A the perpendicular AC = AB, and bisect it in X ; joinC C.V., X C.V., also F MP, G MP, H MP, B MP. At pointsof section K, L, M, E draw parallels to CA: draw… … 62 DRAWING. Here take OA, OB. each = 2; upon AB describe squareACDB: bisect BD in E, and draw EM parallel to CD;describe semicircle and find points F, G, as already shown.Make BK = BD, BH = BE and KL = DE: join L MP,K MP, etc.; also A C.Y., G C.V., etc.; and on eight pointsthus formed describe…
Geometrical drawing · Perspective
