Merchant, F. W. (Francis Walter), 1855-1937, Chant, Clarence Augustus, 1865-1956 · Toronto : Copp Clark · leaf 293
Fig. 314.—Illus-tration of theprinciple ofheatingbuild-ings by hotwater. … Fig. 315.—Hot-water beating system. A,furnace; C, C, C, pipes leading to radia-tors R, R and expansion tank B ; D, I),pipes returning water to furnace afterpassing through radiators. HEATING BY HOT-AIR FURNACES 283 tube D to the bottom of the flask and the colourless waterin G appears at the top of…
Physics
Internet Archive · Western University Libraries · Public Domain Mark 1.0. Free to use for anything.
