An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)

Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 1070

An illustration from An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth, 1888, leaf 1070
stay but thepillars themselves, which, as they are usually proportioned, if they stood alone, without theweight above, could not resist the spreading of the aisles one minute : true, indeed, thegreat load above of the walls and vaulting of the nave should seem to confine the pillars Chap. IV.… … KING S COLI-rCE CHAPEI. : PIERS. Fig 1312. seen at home or abroad, wherein I have not observed the pillars to yield and bend inwardsfrom the weight of the vault of the aisle ; but this defect is the most conspicuous upon theangular pillars of the cross, for there not only the vault wants butment,…
