An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)

Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 1082

An illustration from An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth, 1888, leaf 1082
AMILNS. Fig- 1533. riEKS IS SIDE AlSUiS. The base and capital of the main pillars, as here shown with their dimensions, is thesame as the front view towards the nave, with the exception that the two 7-inch columnsat the side of that in the middle are omitted. The piers tliat divide the side…

Architecture · Architects

Internet Archive · University of Toronto Libraries · Public Domain Mark 1.0. Free to use for anything.
