An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)

Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 116

An illustration from An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth, 1888, leaf 116
V\g.. l^ PLAN ur CUI.I8KUU. diminished, is 28 ft., and the heij^ht of their entablature is 737 ft. The frieze and archi-trave are broken vertically in each Interpilaster over three corbels, on which it is supposed, … SECTION AND ELBVATION OF COMSEUai Fig. 129. running through the hack part of the cornice, poles were placed for holding the velarium,which was occasionally stretched over the building to protect the spectators from the sunor rain. The whole height of the fa9ade above the steps Mas 162 ft. Ilie…
