An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)

Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 692

An illustration from An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth, 1888, leaf 692
oontre, with the distance KE, descrilie the are EH. From I^ as a centre, with tlie distancelAi, describe the arc HP. Proceed in the same manner and complete the rem;<.iningthree quarters, which will finish the outside of the scroll. IMake BR equal to the breadthof the rail J namely, about two…
