An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)
Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 840
e has read,believe he will find difficulty in accomplishing, either by visual rays or other .vise. It isnext to an impossibility to describe intricate matters like these so as to leave nothing forthe exercise of the readers judgment; for, however copious the instruction, there willalways remain… … Fi(!. S3.1. and capitals, whose general forms are shown at X and Y (No. 1.). YZ, as before, is theplane of the picture, S the station jjoint. The picture, as previously, is prepared with thevanishing points VZ, and the ground line GL. OO is the central line of the picture, andBA, BA are, it will be…
