An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)

Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 849

An illustration from An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth, 1888, leaf 849
ill be observed thatwe have not described any of the preceding dia-grams in a strict way, neither shall we do so inthose that follow, presuming that the reader has,from the perusal of the section on Descriptive Geo-metry acquired sufficient knowledge to follow theseveral lines. 2469. The Jig. 845.…
