An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)

Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 853

An illustration from An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth, 1888, leaf 853
Fig. s:.s.parts and verticals from their corresponding ones aa, bb, cc, 8ic. on the plan, and similarlythe shadow of the capital on the wall. In this example, as in those immediately preceding,the employment of sectional lines parallel to the direction of the light is again manifest.The use of…
